200 Degree Radar Level Meter Accuracy 2mm For Liquids And Solids
| Place of Origin | China |
|---|---|
| Brand Name | DTS |
| Certification | CNEX |
| Model Number | DTS-RD-88-A |
| Minimum Order Quantity | 1 |
| Packaging Details | Carton |
| Payment Terms | L/C, T/T, Western Union, MoneyGram |
| Supply Ability | 10000 |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Grade | Industrial | Customized Support | OEM, ODM |
|---|---|---|---|
| Model | DTS-RD-88-A | Application | Solid; Corrosive Liquid With Steam And Foam |
| Measuring Range | 120m | Frequency | 80GHz |
| Process Temperature | -40~+200℃ | Process Pressure | （-0.1~2.5）MPa |
| High Light | 200 Degree Radar Level Meter,Radar Level Meter Accuracy 2mm,radar meter Liquids Solids |
||
Product Description
200℃ 120m Radar Level Meter For Corrosive Liquid Solid 80GHz Radar Level Sensor Transmitter Accuracy 2mm
Product Description:
In continuous non-contact level measurement with radar, the sensor sends microwave signals towards the medium from above. The surface of the medium reflects the signals back in the direction of the sensor. Using the received microwave signals, the sensor determines the distance to the product surface and calculates the level from it.
Liquids and solids are commonly measured with this measuring technique.
Features:
- 80GHz FMCW technology
False echo suppression option
Narrow beam, small blind zone and accurate measurement
Unaffected by temperature fluctuations
Resistant to dirt and buildup
Measurement under vacuum and high pressure
Small size, easy to use, less maintenance - Highly chemically resistant materials ensure long service life of the sensors
Technical Parameters:
| Model | DTS-RD-88-A |
| Application | Corrosive Liquid With Steam And Foam |
| Measuring Range | 120m |
| Frequency | 80GHz |
| Accuracy | ±2mm |
| Process Temperature | -40℃~+200℃ |
| Process Pressure | (-0.1~2.5)MPa |
| Protection Class | IP67 |
| Power Supply | Two wires DC24±6V; Four wires AC220V |
| Output Signal | 4…20mA/HART |
| Connection | Bluetooth/NB-iot/4G |
| Process Connection | Flange from DN80 |
| Material | Stainless Steel+PTFE |
Applications:
The DTS-RD-88-A Non-Contact Radar Level Meter from DTS is a reliable and accurate solution for non-contact level measurement. It is widely used in various industrial applications, such as water treatment, chemical plant, filling systems for pharmaceutical and cosmetic products etc. With its high accuracy, ease of use and reliable performance, the DTS-RD-88-A Non-Contact Radar Level Meter is the ideal choice for any non-contact level measurement requirements.
Packing and Shipping:
The Non Contact Radar Level Transmitter is packaged in a sturdy cardboard box with the following dimensions:
Length: 40 cm
Width: 30 cm
Height: 30 cm
The 80G Radar Level Meter is shipped with all the necessary components and accessories, as well as a user manual.
The package is shipped by air freight, usually with a carrier such as DHL or FedEx.
