High Frequency Radar Level Switch CNEX Stainless Steel Material

Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xGrade | Industrial | Customized Support | OEM, ODM |
---|---|---|---|
Model | DTS-RD | Application | Corrosive And Pressured Liquid |
Measuring Range | 30m | Frequency | 80GHz |
Accuracy | ±2mm | Resolution | 1mm |
Process Pressure | (-0.1~2.5)MPa | Process Temperature | -40℃~+120℃ |
Highlight | High Frequency Radar Level Switch,Radar Level Switch CNEX,level switch radar Stainless Steel |
Hot Sale High Frequency Stainless Steel Material Radar Level Indicator Meter Sensor Transmitter
Product Description:
Radar level measurement with top-down installation of a radar sensor offers perfect application fit in all industries. Non-contact radar with simple commissioning, trouble-free operation saves time and money. For usage in a wide range of applications - be it in simple storage tanks, in corrosive or aggressive media or high accuracy tank gauging applications.
The Non Contact Radar Level Transmitter can realize continuous level measurement of solids and liquids. It can ensure high precision and high stability of measurement under various working conditions. Easy to install, simple to operate and less maintenance, it is an ideal solution for level control in the production process.
As a partner of many brands and a well-known instrument supplier in China, we will ensure the occupational health and safety environment and bright future of your employees with excellent quality and service!
Features:
- 80GHz FMCW technology
False echo suppression option
Narrow beam, small blind zone and accurate measurement
Unaffected by temperature fluctuations
Resistant to dirt and buildup
Measurement under vacuum and high pressure
Small size, easy to use, less maintenance
Technical Parameters:
Model | DTS-RD |
---|---|
Application | Corrosive and Pressured Liquid |
Measuring Range | 30m |
Frequency | 80GHz |
Accuracy | ±2mm |
Resolution | 1mm |
Process Temperature | -40℃~+120℃ |
Process pressure | (-0.1~2.5)MPa |
Process Connection | Flange from DN50 |
Protection Class | IP67 |
Signal output | 4…20mA/HART; RS485/MODBUS |
Connection | Bluetooth/NB-iot/4G |
Material | Stainless Steel+PTFE |
Power Supply | Two Wires DC24±6V; Four Wires AC220V |
Applications:
The 80G Radar Level Transmitter is an advanced microwave level sensor that has a measuring range of 0.15~30m. It uses a unique 80GHz measuring frequency and radar measuring principle to precisely measure the level of various liquids and solids in tanks or other containers. It is suitable for a wide range of applications such as monitoring water levels in reservoirs and rivers, measuring the height of oil in tanks, and detecting the level of materials in silos.
Packing and Shipping:
The 80G Radar Level Meter is packaged in a sturdy cardboard box with the following dimensions:
Length: 40 cm
Width: 30 cm
Height: 30 cm
The 80G Radar Level Meter is shipped with all the necessary components and accessories, as well as a user manual.
The package is shipped by air freight, usually with a carrier such as DHL or FedEx.
