PTFE Radar Level Instrument HART Radar Gauge For Level Measurement

  • PTFE Radar Level Instrument HART Radar Gauge For Level Measurement
  • PTFE Radar Level Instrument HART Radar Gauge For Level Measurement
  • PTFE Radar Level Instrument HART Radar Gauge For Level Measurement
Place of Origin China
Brand Name DTS
Certification CNEX
Model Number DTS-RD-82-C
Minimum Order Quantity 1
Packaging Details Carton
Payment Terms L/C, T/T, Western Union, MoneyGram
Supply Ability 1000

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Grade Industrial Customized Support OEM, ODM
Model DTS-RD-82-C Application Liquid; Corrosive Liquid
Measuring Range 30m Frequency 80GHz
Material Stainless Steel+PTFE Process Temperature -40℃~+120℃
High Light

PTFE Radar Level Instrument

,

Radar Level Instrument HART

,

HART Radar Gauge For Level Measurement
Leave a Message
Product Description

Radar Level Instrument IP67 Protection 80GHz Radar Level Meter Gauge Transmitter Sensor 30m for Corrosive liquid

Product Description:

Radar level measuring instrument is an advanced device for distance measuring. With its optimization on the antenna, it can measure up to 30 meters accurately. Additionally, it comes with powerful microprocessors, allowing the device to analyze signals faster and enables it to be used in complex conditions, such as level of corrossive and pressure liquid. The device is valuable for multiple industries.



Features:

  • 80GHz FMCW technology
    False echo suppression option
    Narrow beam, small blind zone and accurate measurement
    Unaffected by temperature fluctuations
    Resistant to dirt and buildup
    Measurement under vacuum and high pressure
    Small size, easy to use, less maintenance


Technical Parameters:

Model DTS-RD-82-C
Measuring range 30m
Application Corrosive liquid; Liquid
Protection Level IP67
Process Connection Thread G1½; Flange DN50
Power Supply Two Wires DC24±6V; Four Wires AC220V
Connection Bluetooth/NB-iot/4G
Frequency 80GHz
Accuracy ±2mm
Process Temperature -40℃~+120℃
Process Pressure -0.1~0.1MPa
Material Stainless Steel+PTFE
Signal output 4…20mA/HART
Digital output RS485/MODBUS


Applications:

PTFE Radar Level Instrument HART Radar Gauge For Level Measurement 0

Packing and Shipping:

The 80G Radar Level Meter is packaged in a sturdy cardboard box with the following dimensions:

Length: 40 cm
Width: 30 cm
Height: 30 cm
The 80G Radar Level Meter is shipped with all the necessary components and accessories, as well as a user manual.

The package is shipped by air freight, usually with a carrier such as DHL or FedEx.



PTFE Radar Level Instrument HART Radar Gauge For Level Measurement 1
