Compact Radar Level Instrument Meter 4-20mA RS485 Industrial Grade
| Place of Origin | China |
|---|---|
| Brand Name | DTS |
| Certification | CNEX |
| Model Number | DTS-RD-81-A |
| Minimum Order Quantity | 1 |
| Packaging Details | Carton |
| Payment Terms | L/C, T/T, Western Union, MoneyGram |
| Supply Ability | 1000 |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Grade | Industrial | Customized Support | OEM, ODM |
|---|---|---|---|
| Application | Liquid | Frequency | 80GHz |
| Measuring Range | 10m | Process Pressure | -0.1~0.1MPa |
| Process Temperature | -40℃~+120℃ | Process Connection | Thread G3/4 Flange From DN30 |
| High Light | Compact Radar Level Instrument,Radar Level Instrument 4-20mA,radar level meter RS485 |
||
Product Description
Hot Selling Compact 80GHz Radar Level Instrument Sensors Radar Level Indicator Gauge 4-20mA RS485
Product Description:
DTS-RD-81A non-contact radar can realize continuous level measurement of solids and liquids. It can ensure high precision and high stability of measurement under various working conditions. Easy to install, simple to operate and less maintenance, this series is an ideal solution for level control in the production process.
Features:
- 80GHz FMCW technology
False echo suppression option
Narrow beam, small blind zone and accurate measurement
Unaffected by temperature fluctuations
Resistant to dirt and buildup
Measurement under vacuum and high pressure
Small size, easy to use, less maintenance
Technical Parameters:
|
Application |
Liquid and Liquid in small container |
|---|---|
| Measuring range | 10m |
| Frequency | 80GHz |
| Application | Liquid |
| Accuracy | ±2mm |
| Signal output | 4…20mA/HART; RS485/MODBUS |
| Connection | Bluetooth/NB-iot/4G |
| Process Connection | Thread G3/4 Flange from DN30 |
| Process Pressure | -0.1~0.1MPa |
| Material | Stainless Steel+PTFE |
| Protection Level | IP67 |
| Process Temperature | -40℃~+120℃ |
| Power Supply | Two wires DC24±6V ; Four wires AC220V |
Applications:
