80GHz Radar Level Gauge Sensor 1ppm Resolution For Solid Liquid Dust
| Place of Origin | China |
|---|---|
| Brand Name | DTS |
| Certification | CNEX |
| Model Number | DTS-RD-88-B |
| Minimum Order Quantity | 1 |
| Packaging Details | Carton |
| Payment Terms | L/C, T/T, Western Union, MoneyGram |
| Supply Ability | 10000 |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Protection Level | IP67 | Process Connection | Flange From DN80 |
|---|---|---|---|
| Output | RS485/MODBUS; 4…20mA/HART | Power Supply | Two Wires DC24±6V; Four Wires AC220V |
| Temperature Range | -40℃~+200℃ | Measuring Frequency | 80GHz |
| Resolution | 1mm | Measuring Range | 0.15m~120m |
| Process Pressure | （-0.1~0.3）MPa | Connection | Bluetooth/NB-iot/4G |
| High Light | Radar Level Gauge 1ppm Resolution,80GHz Radar Level Gauge,Radar Level Sensor Solid Liquid |
||
Product Description
120m Max 200℃ Radar Level Gauge 80GHz For Solid/Liquid/Dust IP67 1ppm Resolution Sensor Meter Transmitter
Product Description:
Radar Level Gauge is a comprehensive radar level monitoring device designed for industrial and civil applications. It is ideal for measuring liquids, slurries, powders, and granular materials in industries such as petrochemical, water treatment, power, metallurgy, and environmental protection.
Radar Level Gauge is the perfect choice for measuring and monitoring liquid levels in a variety of applications. It is a reliable and cost-effective solution for ensuring a safe and efficient operation. With its high accuracy and reliability, it can provide accurate measurements in all conditions. It is an ideal choice for any industry requiring reliable and accurate level measurement.
Features:
-
The antenna size of the high frequency level sensor is small and easy to install, which enhances its non-contact radar and eliminates any wear and pollution.
-
Almost all forms of corrosion and foam barely effect this radar, and while water vapor, temperature, and pressure changes in the atmosphere may affect it, the changes are minimal.
The shorter wavelength allows the high frequency level sensor to operate better while bouncing signals off of tilted solid surfaces.
-
Additionally, the beam angle is significantly small, which makes the radar more capable of concentrating the energy it uses as well as enhancing the echo ability to better avoid interference objects.
Technical Parameters:
| Parameters | Details |
|---|---|
| Material | Stainless Steel+PTFE |
| Protection Level | IP67 |
| Measuring Frequency | 80Ghz |
| Measuring Range | 0.15m~120m |
| Resolution | 1mm |
| Output | RS485/MODBUS; 4…20mA/HART |
| Process connection | Flange From DN80 |
| Power Supply | Two Wires DC24±6V; Four Wires AC220V |
| Application | Solid/Liquid/Dust Max 200℃ |
| Temperature Range | -40℃~+200℃ |
| Process pressure | (-0.1~0.3)MPa |
Applications:
The 80G Radar Level Gauge is a high-performance level transmitter specifically designed for the measurement of liquids and solids in industrial processes. With its advanced microwave level sensor technology, the 80G Radar Level Sensor is ideal for level measurement in applications such as storage tanks, sewage treatment, and chemical processes, where reliable and accurate level measurement is essential. The device is also well suited for monitoring the levels of corrosive, abrasive, or viscous liquids, and it can be used for slurry or powdery solids as well. The robust design is suitable for use in harsh environments such as petrochemical plants, power plants, oil & gas refineries, and other industrial applications.
Packing and Shipping:
The 80G Radar Level sensor is packaged in a sturdy cardboard box with the following dimensions:
Length: 40 cm
Width: 30 cm
Height: 30 cm
The 80G Radar Level Sensor is shipped with all the necessary components and accessories, as well as a user manual.
The package is shipped by air freight, usually with a carrier such as DHL or FedEx.
The tracking number will be provided to the customer upon shipment to allow for tracking of the shipment.
